ONX2432G028-Open Nextion Genius Series 2.8″ ESP32-S3 AI Smart Touchscreen

Name: ONX2432G028-Open Nextion Genius Series 2.8" ESP32-S3 AI Smart Touchscreen
SKU: 6979033600119
Price: 19.44 USD
Availability: InStock

Original price was: USD$29.90.Current price is: USD$19.44.

[jgm-review-widget]

[jgm-preview-badge]

The ONX2432G028 is an ESP32-S3 smart display with a CTP touchscreen, and its SKU is 6979033600119.
● Out‑of‑the‑box: Access the Open Nextion application platform with continuously updated apps – no coding required for flashing.
● AI‑ready: Powered by ESP32-S3R8 with built-in AI acceleration, supporting AI Vibe Coding to bring your ideas to life faster.
● Wireless connectivity: 2.4GHz Wi‑Fi and Bluetooth 5 (LE) for stable wireless links.
● Extensive expansion: USB‑C, GPIO, I2C, UART, plus interfaces for camera, mic, speaker, RTC battery, Li‑ion battery, and microSD slot – enabling voice interaction, data storage, and multi‑sensor expansion.
● Development support: Full documentation, LVGL compatibility, and support for ESP‑IDF, Arduino IDE, and other mainstream environments.

ONX2432G028-Open Nextion Genius Series 2.8" ESP32-S3 AI Smart Touchscreen

Nextion IO Adapter V2

USD$3.00

Nextion Dual MIC Board

USD$4.99

Secure Payment:

Customer Service Guarantee

Description
Additional information

ONX2432G028 Certification and Documents

Open Nextion Support

Additional information

Weight	100.5 g
Dimensions	145 × 102 × 32 mm
Display Size	2.8"
Resolution	240*320
Touch Panel	CTP
MCU	240 MHz
Flash	16 MB
SRAM	512 KB
PSRAM	8 MB
ROM	384 KB
Interfaces	USB-C(USB to UART), UART0, UART1, I2C, Camera, Microphone, Battery, RTC Battery, SPK
GPIOs	14, IO12-IO13, IO17-IO21, IO38-IO40, IO42, IO45, IO47-IO48 support input and output.
MicroSD Card	Yes
RTC	Yes
Input Power	Input Power DC 5V 1A
Storage Temperature	-30°C ~ 80°C
Working Temperature	-20°C ~ 70 °C
Display Type	TN
Gross Weight	Gross Weight 100.5g
Package Dimensions	145x102x32mm
