nRF24L01 Module

Overview

This module uses the 2.4GHz transceiver from Nordic Semiconductor, the nRF24L01+. This transceiver IC operates in the 2.4GHz band and has many new features! Take all the coolness of the nRF2401A and add some extra pipelines, buffers, and an auto-retransmit feature - very nice!

Note: We now populate these boards with the nRF24L01+. The '+' version of the IC has improved range, sensitivity, and data rates. The command set is backward compatible with the original nRF24L01.

Features

• Voltage: 3-3.6V (recommended 3.3V) V
• Maximum output power: +20dBm
• Emission mode current(peak): 115mA
• Receive Mode Current(peak): 45mA
• Power-down mode current: 4.2uA

Documents

Please visit our wiki page for more info about this product. It will be appreciated if you can help us improve the documents by correcting the errors, adding more demo codes or tutorials.
